E. Starter Button : It operates the electric starter
when clutch lever is depressed with transmission
in any gear. It is recommended to start engine
with transmission in neutral.
F. Light Switch : It has 2 positions. When igntion
switch is ‘ON’, lighting system will work as per
given table.
Day Running Light Feature:
• Day Running light is provided inside the
headlamp.
• Day Running light gets ON
(High intensity)
when ignition switch is turned to ON position.
• After headlight is turned to ON position,
intensity of DRL LED’s will get reduced.
: Taillamp will get ON & DRL ON .
(High Intensity)
: Head lamp, Tail lamp, Number plate
lamp, Speedometer illumination will get
ON & DRL remains ON (Low intensity)
F
E
Igntion
Switch
ON
ON
DRL
ON High Intensity
ON Low Intensity
Light
Switch
OFF
ON
Head
Light
OFF
ON
Day Time
Running Light
(DRL)
Note: The inside of the lamp lens might fog up after
using the motorcycle in rain or after washing. Fog inside
the lamp lens will disappear gradually by switching on
the lamp while driving the motorcycle. The amount of
time it takes for the fog to disperse depends on the
humidity of the ambient air. Fog in non functional areas
other than reflector does not affect the lamp performance.
Control Switch - RH
11
