Bajaj Discover 110 User Manual

The Frame and Engine serial numbers are used to register the motorcycle. They are the unique
alpha-numeric codes to identify your particular vehicle from others of the same model and type.
Frame Number Location
On LH Side of Steering Tube
(Alpha-Numeric - 17 Digits)
Engine Number Location
On LH Side Crankcase Near Gear
Change Lever (Alpha-Numeric - 11 Digits)
Identification Data
4

Bajaj Discover 110 Specifications

General

Displacement	115.45 cc
Max Power	8.6 PS @ 7000 rpm
Max Torque	9.81 Nm @ 5000 rpm
Transmission	4-speed
Fuel System	Carburetor
Fuel Tank Capacity	8 liters
Length	2035 mm
Width	760 mm
Height	1085 mm
Wheelbase	1305 mm
Engine Type	Single cylinder, 4-stroke, Air cooled
Front Suspension	Telescopic
Rear Suspension	Nitrox Gas filled twin shock absorbers
Front Brake	Drum
Rear Brake	110 mm Drum
