Bajaj Discover 110 User Manual

Fitment of Side Cover LH
• Match the Lug provided on rear side (C) of
‘Side Cover’ with the hole located on
chassis & press ‘Side Cover’.
• Match Lug provided on front side (B) of
‘Side Cover’ with hole provided on ‘Fuel
Tank’ and press ‘Side Cover’ inside.
• Match the ‘Side Cover’ properly with
bracket provided on ‘Chassis’ & rotate the
key in anticlockwise direction to lock it.
Removal of Side Cover LH
• Insert the key into the cover lock (A) and
turn the key clockwise.
• Hold the cover with both hands and pull
front side (B) first & rear side (C) later.
Take out ‘Side cover’.
CAUTION : Remove cover as described
above, otherwise cover lugs may break.
A
B
C
Removal & Fitment of Side Cover
12

Bajaj Discover 110 Specifications

General

Displacement	115.45 cc
Max Power	8.6 PS @ 7000 rpm
Max Torque	9.81 Nm @ 5000 rpm
Transmission	4-speed
Fuel System	Carburetor
Fuel Tank Capacity	8 liters
Length	2035 mm
Width	760 mm
Height	1085 mm
Wheelbase	1305 mm
Engine Type	Single cylinder, 4-stroke, Air cooled
Front Suspension	Telescopic
Rear Suspension	Nitrox Gas filled twin shock absorbers
Front Brake	Drum
Rear Brake	110 mm Drum
