Bajaj Discover 110 User Manual

Fitment of Side Cover RH
• Match rear side (C) of ‘Side Cover’ lug with
hole located on air filter & press the cover.
• Match the Lug provided on front side (B) of
‘Side Cover’ with hole provided on ‘Fuel
Tank’ & press ‘Side Cover’ inside.
• Match ‘Side Cover’ properly with bracket
provided on ‘Chassis’ & fix it with Screw (A).
CAUTION : Fit cover as described
above to ensure proper fitment.
A
B
C
Removal of Side Cover RH
• Remove the screw (A) given on ‘Side
Cover’.
• Hold the cover with both hands and pull
front side (B) first & rear side (C) later.
Take out ‘Side cover’.
CAUTION : Remove cover as described
above, otherwise cover lugs may break.
Removal & Fitment of Side Cover
13

Bajaj Discover 110 Specifications

General

Displacement	115.45 cc
Max Power	8.6 PS @ 7000 rpm
Max Torque	9.81 Nm @ 5000 rpm
Transmission	4-speed
Fuel System	Carburetor
Fuel Tank Capacity	8 liters
Length	2035 mm
Width	760 mm
Height	1085 mm
Wheelbase	1305 mm
Engine Type	Single cylinder, 4-stroke, Air cooled
Front Suspension	Telescopic
Rear Suspension	Nitrox Gas filled twin shock absorbers
Front Brake	Drum
Rear Brake	110 mm Drum
