Bajaj Discover 110 User Manual

Removal of Seat
• Remove ‘Side Cover’ LH.
• Pull the ‘Seat Release Cable’ (A) to release
seat lock. Keeping cable pulled, lift the
seat from rear end and slide it towards tail
lamp to remove seat assembly.
Fitment of Seat
• Match & insert the bracket ('1' of Fig. 'B')
of seat with slot ('2' of Fig. 'B') provided
below fuel tank rear mounting on chassis.
• Push seat towards fuel tank and align lock
rod ('3’ of Fig. ‘C') & seat lock ('4' of Fig.
‘C'). Then press the rear portion of seat
from top to lock the seat.
Fig. CA : Seat Release Cable
Fig. B
2
1
A
3
4
Removal & Fitment of Seat
14

Bajaj Discover 110 Specifications

General

Displacement	115.45 cc
Max Power	8.6 PS @ 7000 rpm
Max Torque	9.81 Nm @ 5000 rpm
Transmission	4-speed
Fuel System	Carburetor
Fuel Tank Capacity	8 liters
Length	2035 mm
Width	760 mm
Height	1085 mm
Wheelbase	1305 mm
Engine Type	Single cylinder, 4-stroke, Air cooled
Front Suspension	Telescopic
Rear Suspension	Nitrox Gas filled twin shock absorbers
Front Brake	Drum
Rear Brake	110 mm Drum
