Bajaj Discover 110 User Manual

D
D. Pass Switch : Press switch to flash the head
light.It is used to give signal to vehicles
coming from opposite side while overtaking.
A. Dipper Switch : When headlight is ON,
High or Low beam can be selected with
the dipper switch.
: High Beam : Low beam
B. Turn Signal Switch : When the turn signal
switch is turned to Left ( ) or Right ( )
the corresponding turn signals flash on
and off. To stop turn signal flashing push the
switch in & release.
C. Horn Switch : Press horn switch for sounding
horn.
Hi/Low beam Headlamp Effect of
Switch Status Pass Switch
Low beam Low beam ‘ON’ Hi beam ‘ON’
Hi beam Hi beam ‘ON’ No change
Any
OFF Hi beam ‘ON’
A
B
C
Control Switch - LH
10

Bajaj Discover 110 Specifications

General

Displacement	115.45 cc
Max Power	8.6 PS @ 7000 rpm
Max Torque	9.81 Nm @ 5000 rpm
Transmission	4-speed
Fuel System	Carburetor
Fuel Tank Capacity	8 liters
Length	2035 mm
Width	760 mm
Height	1085 mm
Wheelbase	1305 mm
Engine Type	Single cylinder, 4-stroke, Air cooled
Front Suspension	Telescopic
Rear Suspension	Nitrox Gas filled twin shock absorbers
Front Brake	Drum
Rear Brake	110 mm Drum
