4
Location of Parts
LOCK : Steering locked. Ignition OFF.
OFF : Steering unlock. Ignition OFF.
ON : Steering unlock. Ignition ON.
Steering cum Ignition Lock :
It has three positions.
To Lock the Steering :
To lock the steering, turn the handle bar to the left or
right. Push & release the key. Turn the key to “LOCK”
position and remove the key.
To Unlock the Steering :
To unlock the steering, insert the key in steering cum
ignition lock & turn it clockwise to “OFF” or “ON”
position.
Key :
A common key is used for ‘Steering cum Ignition lock’,
‘Fuel tank cap’ and ‘Side cover lock’.
