Location of Parts
Fuel Tank Cap
• To open the fuel tank cap, lift the flap, insert the
key in the lock and turn it clockwise.
• To lock ‘Fuel Tank Cap’ gently press the cap.
Fuel Tap
Fuel tap lever has following positions.
ON : When fuel level is above Reserve position.
RES : When fuel level is below Reserve position.
OFF : When fuel supply is to be cut off.
Fuel Tank
Cap
Fuel
Tap
OFF
ON
RES
5
