7
“Cranking ON and OFF duration” control:
• During Engine crank cycle cranking is allowed only for
xed duration and in between successive cranks (in
case engine does not start) here is a cooling off
period.
• Cranking on-off duration control feature to avoid
battery discharge-
- 1st Crank ON (5 sec) & Disable for 2 sec.
- 2nd Crank ON (5 sec) & Disable for 2 sec.
- 3rd Crank ON (5 sec) & Disable for 10 sec.
After a gap of 10 sec cranking cycle continues.
• Starter disabled if side stand down: It glows when
side stand is down Under condition-side stand down
& vehicle is in gear, self start will be disabled.
• Headlight control on rpm – Headlamp will be turned
ON only at Engine running condition.
