Baldor 15H SERIES 15H User Manual

Specifications and Product Data 6-7MN715
Ratings Series 15H Custom Control w/Internal DB Transistor
STANDARD 2.5 kHz PWM
CONSTANT TORQUE VARIABLE TORQUE
CATALOG
NO.
INPUT
VOLT
SIZE
Input
Output
Input
Output
NO.
VOLT
Input
Amp
HP KW IC IP
Input
Amp
HP KW IC IP
ID15H215–ER 230 C2 43 15 11.1 42 72 56 20 14.9 54 62
ID15H220–ER 230 C2 57 20 14.9 55 100 70 25 18.6 68 78
ID15H225–ER 230 C2 70 25 18.6 68 116 82 30 22.3 80 92
ID15H230–ER 230 C2 82 30 22.3 80 140 82 30 22.4 80 92
ID15H240–MR 230 D 108 40 30 105 200 134 50 37 130 150
ID15H250–MR 230 D 134 50 37 130 225 134 50 37 130 150
ID15H250V–MR 230 D 134 50 37 130 260 134 50 37 130 150
ID15H415–ER 460 B 21.6 15 11.2 21 42 27.8 20 14.9 27 31
ID15H420–ER 460 C2 28 20 14.9 27 54 35 25 18.7 34 39
ID15H425–ER 460 C2 35 25 18.7 34 58 41 30 22.4 40 46
ID15H430–ER 460 C2 41 30 22.4 40 70 54 40 29.9 52 60
ID15H440–ER 460 C2 57 40 29.9 55 100 54 40 29.9 52 60
ID15H450–ER 460 D 67 50 37 65 115 82 60 45 80 92
ID15H460–ER 460 D 82 60 45 80 140 103 75 56 100 115
ID15H515–ER 575 B 17.5 15 11.2 17 34 22.7 20 14.9 22 26
ID15H520–ER 575 C 23 20 15 22 44 28 25 19 27 31
ID15H525–ER 575 C 28 25 19 27 46 33 30 22 32 37
ID15H530–ER 575 C 33 30 22 32 56 44 40 30 41 47
ID15H540–ER 575 D 44 40 29.8 41 75 56 50 37.2 52 60
ID15H550–ER 575 D 56 50 37 52 92 67 60 45 62 71
ID15H560–ER 575 D 67 60 45 62 109
QUIET 8.0 kHz PWM
CONSTANT TORQUE VARIABLE TORQUE
CATALOG
NO.
INPUT
VOLT
SIZE
Input
Output
Input
Output
NO.
VOLT
Input
Amp
HP KW IC IP
Input
Amp
HP KW IC IP
ID15H215–ER 230 C2 31 10 7.4 30 61 43 15 11.1 42 48
ID15H220–ER 230 C2 43 15 11.1 42 92 56 20 14.9 54 62
ID15H225–ER 230 C2 56 20 14.9 54 92 70 25 18.6 68 78
ID15H230–ER 230 C2 72 25 18.6 70 122 70 25 18.6 68 78
ID15H240–MR 230 D 82 30 22 80 160 107 40 30 104 120
ID15H250–MR 230 D 108 40 30 105 183 134 50 37 130 150
ID15H250V–MR 230 D 134 50 37 130 244 134 50 37 130 150
ID15H415–ER 460 B 15.5 10 7.5 15 30 21.6 15 11.2 21 25
ID15H420–ER 460 C2 22 15 11.2 21 46 28 20 14.9 27 31
ID15H425–ER 460 C2 28 20 14.9 27 46 35 25 18.7 34 39
ID15H430–ER 460 C2 36 25 18.7 35 61 41 30 22.4 40 46
ID15H440–ER 460 C2 41 30 22.4 40 80 41 30 22.4 40 46
ID15H450–ER 460 D 57 40 30 55 92 67 50 37 65 75
ID15H460–ER 460 D 67 50 37 65 122 82 60 45 80 92
ID15H515–ER 575 B 11.3 10 7.5 11 22 17.5 15 11.2 17 20
ID15H520–ER 575 C 18 15 11.5 17 34 23 20 15 22 25
ID15H525–ER 575 C 23 20 15.5 22 38 28 25 19 27 31
ID15H530–ER 575 C 28 25 19 27 47 33 30 22 32 37
ID15H540–ER 575 D 33 30 22.3 32 58 44 40 29.8 41 47
ID15H550–ER 575 D 44 40 30 41 73 56 50 37 52 60
ID15H560–ER 575 D 56 50 37 52 91 67 60 45 62 71
