6-14 Specifications and Product Data MN715
Dimensions Continued
Size B Control
.28 TYP
(7.1mm)
14.65
(372.1mm)
9.25
(235.0mm)
9.25
(225.0mm)
0.28 TYP
(7.1mm)
15.40
(391.2mm)
7.120
(180.9mm)
10.00
(254.0mm)
Air Inlet
Air
Outlet
1.12 Dia.
(28.45 mm)
0.88 Dia.
(22.35 mm)
LOCAL
SHIFT
DISP
RESET
PROG
ENTER
JOG
STOP
REV
FWD
