6-8 Specifications and Product Data MN715
Terminal Tightening Torque Specifications
Table 6-4 Series 15H Stock Products
Tightening Torque
230 VAC
Power TB1 Ground Control J1 B+/R1; B+; B–; or R2 D1/D2
230 VAC
Catalog No.
Lb-in Nm Lb-in Nm Lb-in Nm Lb-in Nm Lb-in Nm
ID15H201–E or W 8 0.9 15 1.7 4.5 0.5 8 0.9 – –
ID15H202–E or W 8 0.9 15 1.7 4.5 0.5 8 0.9 – –
ID15H203–E or W 8 0.9 15 1.7 4.5 0.5 8 0.9 – –
ID15H205–E or W 8 0.9 15 1.7 4.5 0.5 8 0.9 – –
ID15H207–E or W 20 2.5 15 1.7 4.5 0.5 20 2.5 – –
ID15H210–E 20 2.5 15 1.7 4.5 0.5 20 2.5 – –
ID15H210–ER 35 4 50 5.6 4.5 0.5 35 4 – –
ID15H210L–ER 35 4 50 5.6 4.5 0.5 35 4 – –
ID15H215–E 20 2.5 15 1.7 4.5 0.5 20 2.5 – –
ID15H215V–EO 35 4 50 5.6 4.5 0.5 35 4 3.5 0.4
ID15H215V–ER 35 4 50 5.6 4.5 0.5 35 4 – –
ID15H215–EO 50 5.6 50 5.6 4.5 0.5 50 5.6 32 3.6
ID15H215–ER 35 4 50 5.6 4.5 0.5 35 4 – –
ID15H215L–ER 35 4 50 5.6 4.5 0.5 35 4 – –
ID15H220–EO 50 5.6 50 5.6 4.5 0.5 50 5.6 32 3.6
ID15H220–ER 35 4 22–26 2.5–3 4.5 0.5 35 4 – –
ID15H220L–ER 35 4 22–26 2.5–3 4.5 0.5 35 4 – –
ID15H225V–EO 35 4 50 5.6 4.5 0.5 35 4 3.5 0.4
ID15H225V–ER 35 4 50 5.6 4.5 0.5 35 4 – –
ID15H225–EO 50 5.6 50 5.6 4.5 0.5 50 5.6 32 3.6
ID15H225–ER 22–26 2.5–3 22–26 2.5–3 4.5 0.5 22–26 2.5–3 – –
ID15H225L–ER 35 4 22–26 2.5–3 4.5 0.5 35 4 – –
ID15H230–EO 50 5.6 50 5.6 4.5 0.5 50 5.6 32 3.6
ID15H230V–EO 22–26 2.5–3 22–26 2.5–3 4.5 0.5 22–26 2.5–3 3.5 0.4
ID15H230V–ER 35 4 22–26 2.5–3 4.5 0.5 35 4 – –
ID15H230L–ER 22–26 2.5–3 22–26 2.5–3 4.5 0.5 22–26 2.5–3 – –
ID15H240–MO 140 15.8 50 5.6 4.5 0.5 140 15.8 3.5 0.4
ID15H240–MR 140 15.8 50 5.6 4.5 0.5 140 15.8 – –
ID15H240L–MR 140 15.8 50 5.6 4.5 0.5 140 15.8 – –
ID15H250V–MO 140 15.8 50 5.6 4.5 0.5 140 15.8 3.5 0.4
ID15H250V–MR 140 15.8 50 5.6 4.5 0.5 140 15.8 – –
ID15H250–MO 140 15.8 22–26 2.5–3 4.5 0.5 140 15.8 3.5 0.4
ID15H250–MR 140 15.8 22–26 2.5–3 4.5 0.5 140 15.8 – –
