VIGIL3 Voice Alarm
Overview, Architecture and Configuration
VIGIL3 Overview, Architecture & Configuration issue 2
7
• BV3CIF - Copper connections, CAT5 fire rated connection,
Max 100m
• BV3FIFM - Multimode fibre connections, Duplex SC
Termination, fire rated fibre, Max 2KM
• BV3FIFS - Singlemode fibre connections, Duplex SC
T
ermination, fire rated fibre, maximum distance for OS1 is
2KM, and for OS2 is 4KM
Please see the VIGIL3 Networking Installa
tion Manual for more
information regarding these modules.
Regardless of the type of system all VIGIL3 A
udio modules are
connected in a single fault tolerant Ethernet loop.
NOTE: It is important to maintain the Network Out -> Network In
convention throughout a VIGIL3 system. Connecting a Network In to a
Network in or a Network Out to a Network Out will result in a non-
operable system.
