VIGIL3 Voice Alarm
Overview, Architecture and Configuration
VIGIL3 Overview, Architecture & Configuration issue 2
9
For BVRDTSM microphones the mapping of buttons on the
screen to system audio outputs is performed via the BVRDTSM
configuration.
For BDM/BFM microphones the mapping of button to output is
performed in the VIGIL3 Configuration (BDM/BFM Access
Profile). The configuration of the physical microphone is identical
meaning that Vigil 2 microphones can be replaced without
altering any configuration settings.
In both cases any button can cor
respond to any combination of
outputs between 1 and 800.
NOTE: Vigil 2 16 way microphones require 2 x RS485 ports in order
access all 16 buttons. Therefore a BV3AIM4 can only support 2 x Vigil 2
16 way microphones.
