VIGIL3 Voice Alarm
Overview, Architecture and Configuration
VIGIL3 Overview, Architecture & Configuration issue 2
3
• BVRDACO - 10 way AC line monitoring module with
changeover
• BVRDNCO - 10 way AC line monitoring module
• BVRDADC - 10 way DC line monitoring module with
ch
angeover
• BV3ADIM / BV3ADIS - Up to 10 way DC line
monitor
ing modules with changeover and A/B isolation
• BVLAM - 8 Way Impedance Line monitoring module
• Cooling and Power Distribution
• BV3MDPEFM - Exhaust Fan Module - required for all
systems using mains distr
ibution panels below
• BV3MDP05F - 5 way mains distribution and fans,
suppor
ts up to 5 VIGIL3 amplifiers (2 x main frames)
• BV3MDP10F - 10 way mains distribution and fans,
suppor
ts up to 10 VIGIL3 amplifiers (4 x main frames)
• BV3EFM - Single main frame standalone cooling, no
po
wer distribution
• Microphones
• BVRDTSM - Touchscreen voice alarm control
micr
ophone
• BVRDTSMMON - External monitor for BVRDTSM
allo
wing user customisation of graphical interface
• BFM401-408 - Single to 8 w
ay Fire Microphones
• BDM401-416 - Single to 16 way Paging Microphones
NOTE: BVRD Microphones are not supported by VIGIL3 Systems.
Please refer to the individual Hardware Installation Guides for
specific information about the above modules.
