12. Fully install four screws
on other side, and then
fully tighten all screws on
previous side.
13. Using a torque gauge
tighten the eight screws
through the
chassis/frame. Tighten to
12Nm.
14. Apply Loctite (thread-
lock) to screws then
attach bump guard to
unit. Do NOT over-
tighten screws as this
may crack plastic bump
guards.
15. Apply Loctite (thread-
lock) to screws and
attach second bump
guard.
