BALLANTINE LABORATORIES, Inc. MODEL 3207 MICRO-OHM METER
27
COMMAND TOKEN ACTION PERFORMED
CHARACTER ASCII VALUE in HEX
‘0’ 30
Selects 2mΩ Range
‘1’ 31
Selects 20mΩ Range
‘2’ 32
Selects 200mΩ Range
‘3’ 33
Selects 2000mΩ Range
‘4’ 34
Selects 20Ω Range
‘5’ 35
Selects 200Ω Range
‘6’ 36
Selects 2000Ω Range
‘i’ OR ‘I’ 69 OR 49 Increments the range
‘d’ OR ‘D’ 64 OR 44 Decrements the range
‘r’ OR ‘R’ 72 OR 52 Reads the range selected returning the
ASCII value from ‘0’ to ‘6’ of the range.
‘t’ OR ‘T’ 74 OR 54 Reads the 5 digit (Max) count *
‘o’ OR ‘O’ 6F OR 4F Operate Mode
‘s’ OR ‘S’ 73 OR 53 Stand-By mode
*Interpretation of count
For example: If the count is 668,then read the range. If the range is
‘2’ (range=200mΩ), then read the count as 6.68 mΩ.
No.
ASCII
character
Range selected Maximum display
1 ‘0’
2mΩ
1.9999
2 ‘1’
20mΩ
19.999
3 ‘2’
200mΩ
199.99
4 ‘3’
2000mΩ
1999.9
5 ‘4’
20Ω
19.999
6 ‘5’
200Ω
199.99
7 ‘6’
2000Ω
1999.9
