BALLANTINE LABORATORIES, Inc. MODEL 3207 MICRO-OHM METER
32
SECTION 7
OPTIONAL ACCESSORIES
`V+'
`I+'
`I-'
`V-'
C CLAMP
DEVICE UNDER TEST
1. C CLAMP ACCESSORIES
DUT
2. HEAVY DUTY BOND TESTING PROD ASSEMBLY
`V+' `V-'
`I+' `I-'
TO LR METER
TO LR METER
2. HEAVY DUTY BONDING RESISTANCE TEST PROBE ASSEMBLY
