BALLANTINE LABORATORIES, Inc. MODEL 3207 MICRO-OHM METER
33
`I-'`I+'
`V-' `V+'
3. TEST LEAD WITH GOLD PLATED CROCODILE CLIP
DEVICE UNDER TEST
I+ V+ V- I-
DEVICE UNDER TEST
4. TEST LEAD WITH HEAVY DUTY CROCODILE CLIP
`V+'
`I+'
`V+'
`V-'
`I-'
`V-'
TO LR METER
TO LR METER
3. TEST LEADS WITH GOLD PLATED ALLIGATOR CLIPS
4. TEST LEADS WITH HEAVY DUTY ALLIGATOR CLIPS
