BALLANTINE LABORATORIES, Inc. MODEL 3207 MICRO-OHM METER
30
SECTION 6
SPECIFICATIONS
6.1 Electrical:
Range
(Ohm)
Resolution
(Ohm)
Accuracy
+ (% rdg + dgt)
FS rdg.
(Ohm)
DC Current
applied to
DUT
Power
dissipation
in the
sample at
mid-scale
2m 0.1µ +(0.5+5) 1.9999m 1A 1mW
20m 1µ +(0.05+5) 19.999m 1A 10mW
200m 10µ +(0.05+5) 199.99m 100 mA 1mW
2000m 100µ +(0.05+5) 1999.9m 10 mA 0.1mW
20 1m +(0.05+5) 19.999 10mA 1mW
200 10m +(0.05+5) 199.99 1mA 0.1mW
2000 100m +(0.05+5) 1999.9 0.1mA 0.01mW
Note: Accuracies are valid from 1/10
th
of the range to FS of range and valid at.
Temperature: 25
º
C ± 3
º
C at 55% ± 10 % RH.
Tempco. : 150 ppm/
º
C.
Warm up time for stated accuracy – 5 minutes
Over range – blinking Zero display.
6.2 Environmental :
Temperature:
Operating : 0
º
C to 40
º
C
Storage : 0
º
C to 50
º
C
Humidity : < 90% RH Non Condensing.
6.3 General :
Power : 115 VAC ± 10%, 60Hz, single phase (220VAC on order)
Dimensions : 340 (D) x 258(W) x 145(H) mm (approx.)
Net Weight : 3.2 Kg.(approx.) (4.0 Kg. for Option –05)
Shipment Weight : 5.2 Kg. (approx.)
