7.4.3 Connecting cable, preassembled
BKS-S103/GS103-CP-…
Connecting cable, preassembled
M12, 5-pole
Various cable lengths can be ordered, e.g. BKS-S103/
GS103-CP-05: Cable length 5m
Fig. 7-15: Connecting cable BSK-S103/GS203-CP-…
BKS-S103-CP-…
Connecting cable, preassembled
M12, 5-pole
Various cable lengths can be ordered,
e.g.BKS-S103-CP-05: Cable length 5m
Fig. 7-16: Connecting cable BKS-S103-CP-…
BKS-S105-CP-…
Connecting cable, preassembled
M12, 5-pole
Various cable lengths can be ordered,
e.g.BKS-S105-CP-05: Cable length 5m
Fig. 7-17: Connecting cable BKS-S105-CP-…
7.4.4 Bus termination resistance, freely
configurable
BKS-S105-R01
Bus termination resistance, freely configurable
M12, 5-pole
Installed resistors
Fig. 7-18: Bus termination resistance BKS-S105-R01
7.4.5 Transparent cover
BTL5-A-CP01-K
Transparent cover, metric, M16x1.5
Fig. 7-19: Transparent cover, metric M16x1.5
7.4.6 Screw plugs
BKS 12-CS-01
Screw plug, brass, M12x1
Fig. 7-20: Closing cap BKS 12-CS-01 for BUS OUT
7
Accessories (continued)
BTL5-T1 __ -M ____ -P-S103
