2.1 Intended use
In line with its identification, this magnetostrictive linear
position sensor BTL is suitable as electrical equipment
for use in gas and dust explosive areas. When installed in
a machine or system, the BTL forms a position measuring
system in conjunction with a controller or evaluation unit
and may only be used for this purpose.
When selecting the electrical equipment, the person
setting up the machine or system is responsible for
assessing its suitability for the planned area of application.
The information in the user’s guide and other applicable
safety regulations and provisions must be observed during
set-up.
The operator of the machine or system must ensure that
the BTL is applied under the permissible operating
conditions in line with the information in this user’s guide
and in compliance with the applicable safety regulations
and provisions.
Unauthorized interventions, non-permissible use, or
application outside the permissible operating conditions
will result in the loss of warranty and liability claims against
the manufacturer.
2.2 Reasonably foreseeable misuse
The BTL is not approved for use at locations classified as
Zone0 under the North American guidelines.
2.3 Safety measures
The persons setting up and operating the machine or
system must take steps to ensure that a malfunction in the
BTL will not result in hazards to persons or equipment.
This includes the installation of additional safety limit
switches, emergency shutoff switches and maintaining the
permissible ambient conditions. If there are any indications
of damage or malfunctions, the BTL must be immediately
taken out of operation and secured against unauthorized
use.
Even with correct explosion protection, residual risks
remain that could pose a hazard to persons and systems
when the device is correctly operated or if there are any
fault states.
2.4 Approvals, standards, and conformity
The CE Mark verifies that our products
meet the requirements of the current
EMC Directive as well as the ATEX
Directive.
Additional information on directives, approvals and
standards can be found at www.balluff.com on
the product page.
The linear position sensor meets the requirements of the
following product standard:
– EN61326-2-3 (noise immunity and emission)
Emission tests:
– RF emission
EN55011
Noise immunity tests:
– Static electricity (ESD)
EN 61000-4-2
Severity level 3
– Electromagnetic fields (RFI)
EN 61000-4-3
Severity level 3
– Electrical fast transients (burst)
EN 61000-4-4
Severity level 3
– Surge
EN 61000-4-5
Severity level 2
– Conducted interference induced by
high-frequency fields
EN 61000-4-6
Severity level 3
– Magnetic fields
EN 61000-4-8
Severity level 4
The BTL with identification
II 1/2 GD Ex db IIC T6/T5 Ga/Gb Ta –50…+70°C (T6)
–50…+80°C (T5) for gases and
II 1/2 GD Ex ta IIIC T85°C/T100°C Da IP68 Ta
–50°C…+70°C (T85) –50…80°C (T100) for flammable
dusts fulfills the requirements for electrical equipment for
explosive areas in accordance with the following
standards:
– EN60079-0:General requirements
– EN60079-1:Ignition protection “d”
– EN 60079-26: Equipment with equipment protection
level (EPL) Ga
– EN 60079-31: Ignition protection “t”
Compliance is proven through the EC type examination
certificate SIRA 11 ATEX 1104X and a CE declaration of
conformity.
The BTL is certified under certificate
number IECEx SIR 11.0048X.
The current version can be found under
www.iecex.com
Class I Zone 1 A Ex db IIC T* Ga/Gb
T6 Ta –50…70°C, T5 Ta –50…80°C
Class I Zone 1 Ex db IIC T* Gb T6 Ta
–50…70°C, T5 Ta –50…80°C
Class I, Division 1, Groups A,B,C,D
Class II, Division 1, Groups E,F,G;
Class III T6 Ta –50°…70°C, T5 Ta
–50…80°C Type 4X/6P; IP68
2411253
C US
2
EX safety notes
BTL7-A/C/E/G5_ _-M_ _ _ _-J-DEXC-TA12
Magnetostrictive Linear Position Sensor – Rod Style
Type of protection “db” and “ta”
Flameproof enclosure
