www.balluff.com 15english
6.4 Configuration options
Prerequisites
USB communication box connected to the transducer
and PC.
Software correctly installed.
Transducer connected to the power supply.
Magnet on transducer.
Magnets and outputs
One or two magnets can be selected (factory setting:
one magnet)
Two outputs can be assigned independently
Output functions
Position: position in the measuring range.
Speed: speed of the magnet. The sign indicates the
direction of movement. Movement from the null point
to the end point is output with a positive sign.
Movement from the end point to the null point is output
with a negative sign. Max. detectable speed range of
−10to+10m/s.
Speed (no sign): speed of the magnet. The direction
of movement cannot be read. Max. detectable speed
range of 0to10m/s.
Differential position: Distance between two magnets.
Selection is only possible if two magnets have been
selected.
Freely configurable characteristic curve
Null and end points can be read (teach-in) or specified
with the mouse.
The distance between the null point and end point
must be at least 4mm.
The characteristic curve can be inverted or copied from
the other output.
The limits can be adjusted to the measuring range.
The error value can be set in accordance with the
limits.
Boundary conditions for two magnets
Two magnets can only be selected from a nominal
length ≥90 mm.
The distance between two magnets must be ≥65 mm.
DANGER
Uncontrolled system movement
When starting up, if the displacement measurement
system is part of a closed-loop system whose
parameters have not yet been set, the system may
perform uncontrolled movements. This could result in
personal injury and equipment damage.
The system must be taken out of operation before
configuration.
Transducers may only be connected to the
communication box for configuration.
The communication box must be removed after
configuration.
6
Configuration with the Micropulse Configuration Tool (continued)
BTL7-A/E501-M _ _ _ _ -P-S32/S115/KA _ _
Micropulse Transducer in a Profile Housing
