www.balluff.com 5english
1.1 Validity
This guide describes the construction, function and setting
options for the BTL7 Micropulse Transducer with analog
interface. It applies to types BTL7-A/E501-M____-P-
S32/S115/KA__ (see Type code breakdown on
page22).
The guide is intended for qualified technical personnel.
Read this guide before installing and operating the
transducer.
1.2 Symbols and conventions
Individual handling instructions are indicated by a
preceding triangle.
► Handling instruction 1
Handling sequences are numbered consecutively:
1. Handling instruction 1
2. Handling instruction 2
Note, tip
This symbol indicates general notes.
Symbols of this type indicate the LED displays.
1.3 Scope of delivery
– BTL7 transducer
– Mounting clamps with insulating sleeves and screws
– Condensed guide
The magnets are available in various models
and must be ordered separately.
1.4 Approvals and markings
UL approval
File no.
E227256
US Patent 5923164
The US patent was awarded in connection with this
product.
The CE Mark verifies that our products
meet the requirements of the current
EMC Directive.
The transducer meets the requirements of the following
product standard:
– EN61326-2-3 (noise immunity and emission)
Emission tests:
– RF emission
EN55011
Noise immunity tests:
– Static electricity (ESD)
EN 61000-4-2
Severity level 3
– Electromagnetic fields (RFI)
EN 61000-4-3
Severity level 3
– Electrical fast transients (burst)
EN 61000-4-4
Severity level 3
– Surge
EN 61000-4-5
Severity level 2
– Conducted interference induced by
high-frequency fields
EN 61000-4-6
Severity level 3
– Magnetic fields
EN 61000-4-8
Severity level 4
More detailed information on the guidelines,
approvals, and standards is included in the
declaration of conformity.
1
Notes to the user
BTL7-A/E501-M _ _ _ _ -P-S32/S115/KA _ _
Micropulse Transducer in a Profile Housing
