PanelMax installation instructions
Contents
Installation Instructions
1. Safety Warnings! 3
Home Owner Instructions
WARNING! IMPORTANT SAFETY INSTRUCTIONS
FOLLOW ALL INSTRUCTIONS SINCE INCORRECT INSTALLATION CAN LEAD TO SEVERE INJURY.
• before installing the drive, remove all unnecessary ropes or chains and disable any equipment, such as locks, not needed for
powered operation;
• before installing the drive, check that the door is in good mechanical condition, correctly balanced and opens and closes
properly;
• install the actuating member for the manual release at a height less than 1,8 m;
• install any xed control at a height of at least 1,5 m and within sight of the door but away from moving parts;
• permanently x the labels warning against entrapment in a prominent place or near any xed controls;
• permanently x the label concerning the manual release adjacent to its actuating member;
• after installation, ensure that the mechanism is properly adjusted and that the drive reverses when the door contacts a 40 mm
high object placed on the oor.
• necessary information for the safe handling of a drive weighing more than 20 kg. This information shall describe how to use the
handling means, such as hooks and ropes;
• the drive must not be used with a door incorporating a wicket door (unless the drive cannot be operated with the wicket door
open);
• after installation, ensure that parts of the door do not extend over public footpaths or roads.
• vertical doors and gates need an anti-drop feature or device;
• information if a hazardous part of the drive is intended to be installed at a height of at least 2.5 m above oor level or other access
level;
• except for horizontally moving pedestrian doors, ensure that entrapment due to the opening movement of the driven part is
avoided
2. Before you Begin 5
3. Tools Required 5
4. Kit Contents 6
5. Position 6
6. Fit the Opener 7
7. Bracket Position 7
8. Perforated Angle 8
9. Mounting Brackets and Arms 8
10. Optional Safety Beam Kit 9
10.1 Inserting batteries into receiver and transmitter 9
10.2 Assemble the Mounting Bracket 9
10.3 Mounting the Bracket 9
10.4 Aligning the Transmitter and Receiver 9
11. Specifications 10
12. Setting Limits 11
12.1 Set the Limit Positions and adjust drive speed: 11
12.2 Clearing the Door Limit Positions 12
12.3 Re-proling the Door 12
12.4 Controller memory reset 12
13. Safety Testing 13
13.1 Test the Close Cycle 13
13.2 Testing the Open Cycle 13
13.3 Test the Manual Door Operation 13
14. Auto-Close 14
14.1 Auto-Close 14
14.2 Terminal Block 15
14.3 Connecting or Disconnecting Accessories 15
15. Coding a Transmitter 16
15.1 Storing the Transmitter Code 16
15.2 Remotely Coding Transmitters 16
15.3 Erasing All Transmitter Codes 17
15.4 Vacation Mode 17
15.5 Installing the Wall Mounted Transmitter 17
Important Safety Warnings
16. Opener Safety & Security 18
16.1 Your Door CAN NOT be used by the opener when: 18
16.2 Your Door CAN be used when: 18
16.3 To Disengage the Opener: 18
16.4 To Re-engage the Opener: 18
17. Operating your Opener 18
18. User Operating Controls 19
19. Troubleshooting 20
20. Aer Installation Care 22
20.1 Service Checklist 22
20.2 Battery Replacement 23
20.3 Battery Disposal 23
20.4 Warranty 23
21. Appendix 24
A - Status Indication during Operating Mode. 24
B - Adjustment Mode Instructions 25
C - Adjusting Force Margins 26
D - Battery Functions 26
E - Setting the PET mode position 26
F - Setting Limits via Transmitter 27
G - Setting up Tilt Door 28
