B&D PanelMax SDO-8V3 - Appendix; A - Status Indication During Operating Mode

24
PanelMax installation instructions
21. Appendix
A - Status Indication during Operating Mode.
LEDs Light Status Indicates
BLUE GREEN YELLOW RED
DOOR OPEN AND
CLOSED LEDS
solid Open
rapid
ashing
Open with Autoclose timer running
ashing Opening / Obstructed on Open
solid Closed
ashing Closing / Obstructed on Close
ashing ashing Stopped
solid solid Partial Open
MODE LED
ashing Load Diagnostics mode
REMOTE CONTROL STATUS LED
ashing Remote lockout from vacation mode
rapid
ashing
Remote Control Activity
