Bandit
99Copyright 8/19
MODEL 2290
Parts may not be exactly as shown.NOTICE
KNIFE BOLTS MUST BE INSTALLED THROUGH KNIFE AS SHOWN.
NOTICE
Torque Knife Bolt to 180 ft.-lbs. (244 Nm)
Torque Knife Holder Bolt to 250 ft.-lbs. (339 Nm) with Loctite 243 (Blue)
LOCATION PART NUMBER DESCRIPTION
LOCATION PART NUMBER DESCRIPTION
1. 500-0001-16 Knife Saver Kit
2. 900-9901-65 File For Knife Saver Kit Only
3. 900-9914-29 Replacement Blades For Knife Saver
4. 900-9914-24 Knife Changing Gloves
KNIFE SAVER KIT
4
1
CHIPPER KNIFE & HARDWARE
BOLT IN STYLE KNIFE
1. 938-301104 Knife Holder
2. 900-4914-30 3/4”-10NC x 2 1/4” SHCS Knife Holder Bolt
3. 900-9904-38 Knife
4. 900-4901-32 5/8” Washer
5. 900-4913-99 5/8”-11UNC x 1 1/2” GR 8 Hex Head Bolt
6. 930-1001-43 Complete Drum Knife Holder Assembly
