Bandit 2290 - Replacement Parts Section; Machine Orientation Reference for Parts

Bandit
87Copyright 8/19
MODEL 2290
MACHINE ORIENTATION REFERENCE
Depending on what replacement parts you are ordering
the following information will be needed:
CHIPPER COMPONENTS
Serial Number
Model Number of Chipper
ENGINE COMPONENTS
Brand
Engine Serial Number
Engine Spec. Number
CLUTCH COMPONENTS
Brand
Serial Number
Assembly Number of Clutch
REPLACEMENT PARTS
REPLACEMENT PARTS SECTION
When ordering any replacement parts you should have the serial number (S/N) and model of the machine
to ensure that you receive the correct replacement part. See page 6 for typical serial number & work order
number locations.
NOTICE
Bandit Industries Inc. reserves the right to make changes in models, size, design, installations and applications
on any part without notication.
NOTICE
Some of the components shown in this section are for optional equipment and may not apply to every machine.
NOTICE
All nuts, bolts, washers, and many other components can be ordered by physical description.
NOTICE
RADIATOR
SIDE
DRIVE
SIDE
I N F E E D H O P P E R
END
DISCHARGE
END
RADIATOR
SIDE
DRIVE
SIDE
DISCHARGE
END
I N F E E D H O P P E R
END
