Bandit 2290 - Frame & Accessory Components

Bandit
107Copyright 8/19
MODEL 2290
** Order Brake Hub And Drum Assembly According To Axle Type.
(Grease Type, Oil Type, Never Lube Type).
*-* Engine Rails And Adjusters Will Vary Depending On Engine And Component Options.
Order By Serial Number Of Chipper Or Physical Description.
FRAME & ACCESSORY COMPONENTS
PINTLE FRAME
LOCATION PART NUMBER DESCRIPTION
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
1. 977-301530 Poly Tail Light Cover
2. 900-2923-53 LED Tail Light
3. 900-2909-60 LED Marker Light Red
4. 900-2914-94 Rubber Grommet for LED Marker Light
5. 900-2908-75 Rubber Grommet for LED Marker Light
6. a. 259-2001-41 Tail Light Box left side (Radiator Side)
b. 259-2001-42 Tail Light Box right side (Drive Side)
7. 900-2927-84 License Plate Light
8. 959-8000-32 LED 3 Light Bar & Mount
9. 938-3013-10 Tail Light Bracket left side (Radiator Side)
10. 938-3013-11 Tail Light Bracket right side (Drive Side)
11. 900-2902-41 Junction Box
12. 259-2002-73 Front Stabilizer Assembly (Radiator Side) See page 116
13. 259-2000-67 Front Stabilizer Assembly (Drive Side) See page 116
14. 259-1001-63 Battery Box Assembly See page 117
15. 900-5909-31 Mud Flap
16. 259-3020-42 Mud Flap Mount Plate
17. 914-1000-38 Pin Assembly (Rear Stabilizer)
18. 900-3934-24 Rear Stabilizer Cylinder
19. 259-2001-87 Rear Stabilizer Leg Assembly
20. 900-5908-88 Suspension Assembly
21. 900-5909-43 Axle Assembly 25,000#
22. a. 900-5909-17 Tire & Wheel
b. 900-5909-16 Wheel Only
c. 900-5909-15 Tire Only
23. 259-2002-60 Grapple Barrel Assembly
24. 900-5900-71 3” Pintle Hitch
25. 977-100053 Safety Chain Assembly
