Bandit 2290 - Base Components

Bandit
93Copyright 8/19
MODEL 2290
LOCATION PART NUMBER DESCRIPTION
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
BASE COMPONENTS
2290 TRAILER BASE
** Components vary with engine options, refer to check sheet or machine S/N.
1. 249-1000-81 Base Assembly
2. 900-1921-85 Drum Bearing Kit
3. See Page 99 Anvil
4. See Page 97 Drum Head Assembly
5. 911-1001-88 Vent Cover
6. 900-4908-29 Vent Cover Plastic Knob
7. 937-300007 Air Vent Cover
8. 259-3002-37 Base/Chipper Shaft Slot Cover
9. 249-2002-13 Hinged Hood Assembly
10. 249-3001-56 Knife Access Door Plate
11. 249-2000-98 Top Belly Band Front Half (Trailer)
12. a. 938-3014-11 Hinged Hood Lock Pin
b. 259-3004-34 Hood Pin Chain
13. 900-2916-31 Engine Disable Switch
14. 938-3014-13 Hinged Hood Lock Pin Hold Down Plate
15. 249-2001-70 Chip Breaker Assembly (Top Discharge)
16. 249-2000-60 Transition Assembly w/Clean-Out Door (Optional Over the Top Discharge)
17. 249-3003-33 Chip Slot Cover (2290 1” Chip)
18. 249-3005-93 Base/Divider Fill Outer Plate (Top Discharge)
19. 249-2001-43 Top Belly Band Back Half (1” Chip)
20. 249-2001-72 2290 Discharge Chute Base Assembly
21. 249-2001-41 Discharge Hood Assembly (Drop in Breakers)
22. 900-1917-38 Drive Sheave
23. 900-1918-33 Drive Bushing
24. ** Driven Bushing
25. ** Driven Sheave
26. ** Chipper Belt
27. ** Belt Shield Assembly
