Bandit 2290 - Page 109

Bandit
105Copyright 8/19
MODEL 2290
LOCATION PART NUMBER DESCRIPTION
OVER THE TOP DISCHARGE - OPTIONAL
DISCHARGE COMPONENTS
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
1. 249-2000-62 Folding Discharge w/Replaceable Top
2. 249-3003-00 Upper Folding Discharge Replaceable Top
3. 900-3928-16 Discharge Locking Cylinder
4. 249-3003-40 Discharge Locking Cylinder Pin
5. 900-3917-25 Stau󰀨 Clamp 1/4” Double
6. a. 249-3005-78 Discharge Lower Rotate/Pivot Pin
b. 900-4902-37 1/4” Lynch Pin
7. 249-2000-61 Folding Discharge Bottom
8. a. 900-1901-34 Folding Discharge Drive Chain
b. 900-1901-89 Drive Chain Master Link
c. 900-1903-22 Drive Chain Half Link
9. 900-1910-25 Folding Discharge Drive Sprocket
10. 975-200028 Discharge Motor Mount
11. 900-3973-40 Discharge Hydraulic Motor
12. 937-1008-47 Clean-Out Frame (Optional)
13. 249-2000-60 Transition Assembly
14. 900-3953-08 Discharge Fold Cylinder
15. 903-3003-06 Folding Discharge Clean-Out Door
16. 900-3949-09 Dual Pivot Valve
17. 249-2000-78 Folding Discharge Round Flipper Assembly
18. a. 249-2002-48 Folding Discharge Flipper Pin Assembly
b. 900-4902-37 1/4” Lynch Pin
19. 900-3943-75 Folding Discharge Flipper Cylinder
