MODEL 2290 HYDRAULIC COMPONENTS
CONTROL VALVE
LOCATION PART NUMBER DESCRIPTION
LOCATION PART NUMBER DESCRIPTION
TYPICAL SPRING LOADED CONTROL VALVE COMPONENTS
Parts may not be exactly as shown.NOTICE
1. 904-0003-29 Handle Only (Long)
2. 900-3905-95 Valve Bracket Only With Screws
3. 904-0003-30 Master Link Only Control Valve
4. 904-0003-31 Pin And Cotter Key For Control Valve
5. 904-0003-32 Bracket, Handle And Chain Link
NOTE: INCLUDES #’s 1, 2, 3, 4
6. 900-3937-34 Seal Kit For Control Valve
7. 904-0003-33 Seal Retainer For Control Valve
NOTE: NOT INCLUDED IN SEAL KIT
8. 900-3901-12 Relief Valve Kit - Spring, Ball, Screw
NOTE: SOLD ONLY AS A KIT
9. 904-0003-34 Valve Spool Stop For Spring Loaded Valve
10. 904-0003-35 Valve Spool Spring
11. 904-0003-36 Valve Spacer For Yoke Lift Valve
12. 900-A-2941 Spring Center Kit For Spring Loaded Valve
13. 904-0003-37 Detent Cap Only For Spring Loaded Valve (Short)
1. 900-3920-01A Tongue Jack / Rear Stabilizer
