Bandit 2290 - Hydraulics; Hydraulic Pressure and Flow Settings

Bandit
81Copyright 8/19
MODEL 2290
TYPICAL HYDRAULIC PRESSURE SETTINGS
TYPICAL HYDRAULIC FLOWS AND RPM SETTINGS
(Approximate, For Reference Only, Engine At Full RPM)
After the initial start-up of the machine and after any replacement of hydraulic components, that ttings
and hoses should be re-checked for leaks and clearances.
DO NOT UNDER ANY CIRCUMSTANCES OVER-SET THESE RELIEF PRESSURES, BECAUSE IT WILL
CAUSE DAMAGE TO COMPONENT PARTS AS WELL AS HYDRAULIC PARTS.
These typical hydraulic ows and relief pressure settings are with the engine at full RPM. All settings are
subject to change!
NOTICE
NOTICE
CAUTION
!
HYDRAULICS
Equipment Model 2290 2290T
Top Feedwheel
PSI (bar)
2300
(158)
2300
(158)
Bottom Feedwheel
PSI (bar)
2300
(158)
2300
(158)
Yoke
PSI (bar)
A - 1500 / B - 1150
(A - 103 / B - 79)
A - 1500 / B - 1150
(A - 103 / B - 79)
Yoke Lock
PSI (bar)
A - 1500 / B - 1150
(A - 103 / B - 79)
A - 1500 / B - 1150
(A - 103 / B - 79)
Discharge Lock
PSI (bar)
800
(55)
800
(55)
Discharge Fold
PSI (bar)
800
(55)
800
(55)
Conveyor Drive
PSI (bar)
2300
(158)
2300
(158)
Discharge Rotate
PSI (bar)
1500
(103)
1500
(103)
Loader Swing
PSI (bar)
1600
(110)
1600
(110)
Flipper Left / Right
PSI (bar)
1000
(69)
1000
(69)
Flipper Up / Down
PSI (bar)
1000
(69)
1000
(69)
Front Stabilizer
PSI (bar)
2200
(152)
N/A
Rear Stabilizer
PSI (bar)
1000
(69)
N/A
Tracks
PSI (bar)
N/A
5000
(345)
Equipment Model Loader
Loader Main Up
PSI (bar)
2300
(158)
Loader Main Down
PSI (bar)
1000
(69)
Jib In / Out
PSI (bar)
2300
(158)
Grapple Open/
Close
PSI (bar)
2300
(158)
Grapple Rotate
PSI (bar)
2300
(158)
