Bandit
89Copyright 8/19
MODEL 2290 INFEED HOPPER COMPONENTS
LOCATION PART NUMBER DESCRIPTION
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
2290 TRAILER INFEED
1. 249-2000-28 Rear Bumper Assembly
2. 900-1906-33 Bearing
3. 900-4902-75 Adjuster Eye Bolt 5/8” x 6”
4. 249-2000-08 Infeed Conveyor Idler Wheel Assembly
5. 249-3001-06 Infeed Conveyor Trap Door
6. 259-2000-58 Infeed Conveyor Drive Wheel Assembly
7. 900-1915-56 Infeed Conveyor Drive Bearing
8. 955-0501-47 Infeed Conveyor Chain Assembly (Paddles 47 Links)
9. 900-1914-58 Infeed Chain Drive Bushing
10. 900-1915-53 Infeed Chain Drive Sprocket
11. a. 900-1922-86 Infeed Drive Chain (Includes b. & c.)
b. 900-1913-26 Infeed Drive Chain Master Link
c. 900-1913-27 Infeed Drive Chain Half Link
12. a. 900-1922-85 Infeed Drive Chain (Includes b. & c.)
b. 900-1913-26 Infeed Drive Chain Master Link
c. 900-1913-27 Infeed Drive Chain Half Link
13. 900-1915-55 Bottom Feedwheel Drive Bushing
14. 259-2002-72 Conveyor Drive Gear Box Mount
15. 900-3942-59 Gear Box
16. 900-6907-69 Gasket
17. 900-3943-57 Hydraulic Motor (Infeed/Bottom Feedwheel)
18. 259-2000-84 Yoke Stop Assembly
19. 920-300330 Yoke Support Top
20. 249-2000-27 Top Feedwheel Assembly
21. 900-3925-07 Yoke Lift Cylinder
22. 937-300285 Yoke Slide
23. 900-1915-54 Top Feedwheel Driven Sprocket
24. 259-2000-54 Chain Guard Assembly
25. a. 900-1922-81 Top Feedwheel Drive Chain (Includes b. & c.)
b. 900-1910-16 Master Link
c. 900-1910-15 Half Link
26. 900-1903-43 Top Feedwheel Drive Bushing
27. 900-1907-97 Top Feedwheel Drive Sprocket
28. 259-1001-70 Top Drive Mount Assembly
29. 900-3906-29 Top Feedwheel Hydraulic Motor
30. 900-1902-42 Yoke Cylinder Bushing
31. 259-2000-10 Top Yoke Assembly
32. 900-3928-16 Yoke Lock Cylinder
33. 977-305502 Yoke Lock Pin
34. 259-2000-60 Yoke Lock Pin Assembly
35. 249-2000-04 Bottom Feedwheel Assembly
36. 249-2000-01 Trap Door Assembly
37. 955-300086 Lock Pin
38. 249-3009-77 Chain Drive Cover Plate
