Bandit
95Copyright 8/19
MODEL 2290 BASE COMPONENTS
2290 TRACK BASE
LOCATION PART NUMBER DESCRIPTION
** Components vary with engine options, refer to check sheet or machine S/N.
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
1. 249-1000-95 Base Assembly
2. 900-1921-85 Drum Bearing Kit
3. 259-2001-06 Base/Shaft Cover Assembly
4. See Page 101 Anvil
5. See Page 97 Drum Head Assembly
6. 911-1001-88 Vent Cover
7. 900-4908-29 Vent Cover Plastic Knob
8. 937-300007 Air Vent Cover
9. a. 259-3000-52 Base/Chipper Shaft Slot Cover (Drive Side)
b. 259-3002-37 Base/Chipper Shaft Slot Cover (Radiator Side)
10. 249-2002-05 Hinged Hood Assembly
11. 249-3001-56 Knife Access Door Plate
12. 249-2001-54 Top Belly Band Front Half (Track)
13. 249-2001-75 Upper Belly Band Assembly w/Breakers
14. See Page 96 Stick Breaker Assembly (Single Replace)
15. ** Drive Sheave
16. ** Drive Bushing
17. ** Chipper Belt
18. ** Beltshield Assembly
19. ** Driven Bushing
20. ** Driven Sheave
To Next Page
