B&PLUS RCS600 - Page 24

- 24 -
Wireless charging system 600W specication
For 12V・24V・48V battery
current(A)current(A) voltage(V)voltage(V)
time(s)
current(A) voltage(V)
current(A)
voltage(V)
<Communication function>
Communication machine is equipped with the passive head and active head of the unit.
Performs wireless communication with the communication unit, we are charging control and state
control of the battery.
【 Using RCS600(B)-CA48】
Battery [CYCLON-G G-16EP(four 12V batteries connected in series] 50%（8A ｈ）
Charge characteristics after discharge
（Constant power(600W) Max.12A CV Voltage 57.6V）
Battery [CYCLON-G G-16EP(four12V batteries connected in series]
50%（8A ｈ）Charge characteristics after discharge
（Constant power(600W) Max.10A CV voltage 57.6V ）
*When the set current is low, the upper limit current is maintained even if the charging voltage rises,
resulting in a charging curve similar to CC-CV charging.
RCS600
CA
48
RCS600
CA
48
time(s)
