B&W Tek NanoRam Series User Manual

NanoRam
®
Series Handheld Raman
19 Shea Way, Newark, DE 19713, USA • Tel: +1 (302) 368-7824 • Fax: +1 (302) 368-7830 • Web: www.bwtek.com
290020255-J (2017/07/28) Page 12 of 38 Copyright 2017 B&W Tek
Version A:
Hold the ring and turn it counterclockwise 1/8
th
turn to unlock.
Carefully pull out the battery cover and set aside.
Insert the provided NanoRam Lithium Ion battery pack
into the battery compartment as shown. Battery contacts
should be facing down (towards the back of the unit) and
to the right. The strap attached to the battery pack can be
used for battery insertion as well as removal. Assure that
the battery is fully inserted.
Install the battery cover back in the same position as removed.
Use thumbs and/or fingers to firmly press the cover into place to
assure correct positioning and to establish a tight seal.
