Turn the ring clockwise 1/8
th
turn till the ring is in a vertical
position.
The cover is now locked.
Version B:
Hold the ring. Turn it clockwise 1/8
th
turn to unlock.
Turn it counterclockwise 1/8
th
turn till the ring is in a vertical
position to lock.
Note: The battery can be charged either through the supplied external power adaptor or using the optional charging
cradle.
