Banner DF-G1 User Manual

For Sales and Support, Contact Walker EMD • Toll-free: (800) 876-4444 • Tel: (203) 426-7700 • Fax: (203) 426-7800 • www.walkeremd.com
Opposed Mode Diffuse Mode
.04" Diameter Fibers
PIT46U
HS/STD
LR
XLR
0
1000 200 300 400 500 600 700 800 900 1000
DISTANCE (mm)
BEAM WIDTH (mm)
0
-100
-200
-300
-400
-500
-600
100
200
300
400
500
600
PBT46U
-200
-150
-100
-50
0
50
100
150
200
0 40 80 120 160 200 240 280 320
BEAM WIDTH (mm)
DISTANCE (mm)
HS/STD
LR
XLR
.06" Diameter Fibers
PIT66U
HS/STD
LR
XLR
0 100 200 300 400 500 600 700 800
DISTANCE (mm)
BEAM WIDTH (mm)
0
-100
-200
-300
-400
100
200
300
400
PBT66U
BEAM WIDTH (mm)
DISTANCE (mm)
-80
-60
-40
-20
0
20
40
60
80
0 20 40 60 80 100 120 140 160 180 200
HS/STD
LR
XLR
DF-G1 - Expert Dual Display Fiber Amplifier Manual
24 www.bannerengineering.com - tel: 763-544-3164 P/N 161999 Rev. A
