Banner Q5X Reference Guide

Octet 3
Subindex 4 4 4 4 4 3 2 1
Bit offset 7 6 5 4 3 2 1 0
Value 1 1 1 1 1 1 0 1
Example Based on the Value Above
Channel 1 Output = Active
Channel 2 Output = Inactive
Stability State = Stable
Measurement 1 Value = 8191
Measurement 2 Value = 694
Process Data (If Binary Data Is Not Included)
Process Data Input
Subindex Name Number of Bits Data Values
1 Measurement 1 Value 16 Value depends on "Configuration.Measurement 1
Selection"
2 Measurement 2 Value 16 Value depends on "Configuration.Measurement 2
Selection"
Octet 0
Subindex 2 2 2 2 2 2 2 2
Bit offset 31 30 29 28 27 26 25 24
Value 0 0 0 0 0 0 1 1
Octet 1
Subindex 2 2 2 2 2 1 1 1
Bit offset 23 22 21 20 19 18 17 16
Value 0 1 0 0 1 0 1 1
Octet 2
Subindex 1 1 1 1 1 1 1 1
Bit offset 15 14 13 12 11 10 9 8
Value 0 1 1 0 0 1 1 1
Octet 3
Subindex 1 1 1 1 1 1 1 1
Bit offset 7 6 5 4 3 2 1 0
Value 1 0 0 0 1 1 1 1
Example Based on the Value Above
Measurement 1 Value = 26511
Measurement 2 Value = 843
IO-Link Process Data Out (Master to Device)
Process Data Output
Subindex Name Number of Bits Data Values
1 Transducer Disable 1 0 = Active
1 = Inactive
IO-Link Data Reference Guide: Q5X Sensor
2 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 206834 Rev. B
