14 Components and Accessories
14.1 Replacement Parts and Accessories
Model Description Applicable Product
SC-USB2 USB cable XS/SC26-2, SC10-2
SC-XMP2 Programming tool for SC-XM2/3 XS/SC26-2, SC10-2
DIN-SC DIN End Clamp XS/SC26-2, SC10-2
SC-XM2 External memory drive for the XS/SC26-2 XS/SC26-2
SC-XM3 External memory drive for the SC10-2 XS/SC26-2, SC10-2
SC-TS2 Screw terminal blocks controller XS/SC26-2
SC-TS3 Screw terminal blocks expansion module XS/SC26-2
SC-TC2 Spring cage terminal blocks controller XS/SC26-2
SC-TC3 Spring cage terminal blocks expansion module XS/SC26-2
14.2 Ethernet Cordsets
Cat5e Shielded Cordsets Cat5e Crossover Shielded Cordsets Length
STP07 STPX07 2.1 m (7 ft)
STP25 STPX25 7.62 m (25 ft)
STP50 STPX50 15.2 m (50 ft)
STP75 STPX75 22.9 m (75 ft)
14.3 Interface Modules
See datasheet p/n 62822 and p/n 208873 and
EDM and FSD Hookup
on page 53 for more information.
Model Input Voltage Inputs Safety Outputs Aux. Outputs Output Rating EDM Contacts
IM-T-9A
24 V dc
2 (dual-channel
hookup)
3 N.O. —
6 amps
2 N.C.
IM-T-11A 2 N.O. 1 N.C.
SR-IM-9A 3 N.O. —
See datasheet for
specifications
SR-IM-11A 2 N.O. 1 N.C.
14.3.1 Mechanically Linked Contactors
Mechanically Linked Contactors provide an additional 10 or 18 amp carrying capability to any safety system. If used, two
contactors per Safety Output pair are required for Category 4. A single OSSD output with 2 contactors can achieve
Category 3. The N.C. contacts are to be used in an external device monitoring (EDM) circuit.
See
EDM and FSD Hookup
on page 53 for more information.
Model Supply Voltage Inputs Outputs Output Rating
11-BG00-31-D-024
24 V dc 2 (dual-channel hookup) 3 N.O. and 1 N.C.
10 amps
BF1801L-024 18 amps
XS/SC26-2 and SC10-2 Safety Controllers
154 www.bannerengineering.com - Tel: + 1 888 373 6767
