TL50 Basic Wireless Andon Tower Light Instruction Manual
Segments—maximumcurrentperLEDsegment:45mAat18
V DC to 30 V DC
Omni-Directional Audible Alarm:25mAmaximumcurrent
Supply Protection Circuitry
Protected against transient voltages
Input
PNP power only
Input Response Time
Indicator On/Off: 10 milliseconds maximum
Operating Frequency
2.7kHz±500Hzoscillationfrequency
AudibleIntensity:92dBat1m(typical)
Connections
Integral 4-pin M12 quick-disconnect connector
Models with a quick disconnect require a mating cordset
Construction
Bases and Covers:Polycarbonate
Light Segment:Polycarbonate
VibrationandMechanicalShock
Meets IEC 60068-2-6 requirements (Vibration: 10 Hz to 55
Hz, 0.5 mm amplitude, 5 minutes sweep, 30 minutes dwell)
Meets IEC 60068-2-27 requirements (Shock: 15G 11 ms
duration, half sine wave)
Operating Conditions
Non-Audible:–40°Cto+50°C(–40°Fto+122°F)
Audible:–20°Cto+50°C(–4°Fto+122°F)
95% at +50 °C maximum relative humidity (non-condensing)
Environmental Rating
Assembly:IP54
Stand-alone tower light:IP65
Indicator Characteristics
Color
Dominant Wavelength (nm) or
ColorTemperature(CCT)
Lumen Output
(Typicalat25°C)
Green 525nm 16.5
Red 625nm 6
Yellow 590nm 15
Blue 465 nm 4
Required Overcurrent Protection
WARNING: Electrical connections must
be made by qualified personnel in
accordance with local and national
electricalcodesandregulations.
Overcurrent protection is required to be provided by end
productapplicationperthesuppliedtable.
Overcurrent protection may be provided with external fusing
or via Current Limiting, Class 2 Power Supply.
Supply wiring leads < 24 AWG shall not be spliced.
For additional product support, go
towww.bannerengineering.com.
Supply
Wiring
(AWG)
Required Overcurrent
Protection (A)
Supply
Wiring
(AWG)
Required Overcurrent
Protection (A)
20 5.0 26 1.0
22 3.0 28 0.8
24 1.0 30 0.5
Certifications
Banner Engineering BV
Park Lane, Culliganlaan 2F bus 3
1831 Diegem, BELGIUM
Radio Range
900 MHz (500 mW): Up to 1.6 km (1 mile) (internal antenna)
2.4 GHz: Up to 1000 m (3280 ft) with line of sight (internal
antenna)
Antenna Minimum Separation Distance
900 MHz (500 mW): 4.57 m (15 ft) with the supplied 2 dB
antenna
2.4 GHz, 65 mW: 0.3 m (1 ft)
Radio Transmit Power
900 MHz Conducted: 27 dBm (500 mW); EIRP with the
supplied 4 dB antenna: 31 dBm (1260 mW)
2.4 GHz Conducted: < 18 dBm (65 mW); EIRP with the
supplied 2 dB antenna: < 20 dBm (100 mW)
Spread Spectrum Technology
FHSS (Frequency Hopping Spread Spectrum)
900 MHz Compliance
Radio module is indicated by the product label marking
Contains FCC ID: UE3RM7023: FCC Part 15, Subpart C,
15.247
ContainsIC:7044A-RM7023
2.4 GHz Compliance (SX243 Radio Module)
Radio module is indicated by the product label marking
Contains FCC ID: UE3SX243: FCC Part 15, Subpart C,
15.247
Radio Equipment Directive (RED) 2014/53/EU
ETSI/EN: EN 300 328 V2.2.2 (2019-07) [RED HarmStds]
Contains IC: 7044A-SX243
Dimensions
All measurements are listed in millimeters [inches], unless noted otherwise.
