Baofeng UV-5RM PLUS - Radio Overview; Controls and Buttons Identification

Chapter4. Radio Overview
4.1 Buttons and controls of the radio
1. Power/Volume knob 2.SK1- Broadcast FM and Alarm key 3. PTT key
4. VFO/MR mode key 5. Status LED 6. SK2-Flashlight and Monitor key
7. A / B select key 8. Key (MENU) 9. Numeric keypad
10. Antenna jack. 11. LED flashlight 12. Color LCD
13. Accessory jack 14. Speaker and microphone 15. One-Touch search key
16. Key (EXIT) 17.  or  navigation keys 18. Type-C charging port
19. Type-C charging indicator 20. Battery release latch
-10-
