Baofeng UV-5RM PLUS - Technical Specifications; General Radio Specifications

Appendix C. - Technical Specifications
General
Receiver Frequency FM 76-108 MHz; AM 108-136MHz,
VHF 136-174MHz, 220-260MHz,
UHF 350-390MHz, 400-520MHz
Transmission Frequency 144-148 & 420-450MHz （America version)
144-148 & 430-450MHz （Canadian version)
Channel Spacing 25.0KHz(Wide)/12.5KHz(Narr)
Memory Channel 999 Groups
Operation Voltage DC 7.4 V ±10%
Transmission current ≤2800mA
Receive Sensitivity 0.25μV (12dB SINAD)
Rated Audio Power Output 1W @16 ohms
Receive current ≤380mA
Connection for accessories 2 pin Kenwood jack
Antenna impedance 50 Ohm
NOTE: All specifications may be modified without prior notice or liability. Thank you.
The M version supports AM108-136, Police350-390MHz scanning reception, and voice scrambling functions. The L version
does not support AM108-136, Police350-390MHz scanning reception, and voice scrambling functions.
-37-
