Function and working condition of operation device and meter:
Pull the lever backward fully.
Adjust hand wheel’s
angle.
Depress the pedal to brake.
Change traveling
direction.
Pull the lever forward, the truck
travels forward.
Refer to Chapter Electric System in this manual.
Connect the meter and power
when turning right (shiftⅠ).
Control head
combination lamp,
headlamp, rear lamp.
Push or pull the double-shift
switch when lighting.
The horn sounds when pressing
the button.
Operating lever,
turning lights
Indicate turning
direction.
Pull operating lever when turning.
Operating lever,
lift cylinder
Mast lifts when pulling backward,
descends when pushing forward.
Operating lever,
tilt cylinder
Tilt backward when pulling
backward, it’s forward oppositely.
Press the rear button of battery
cover to open the lock
2.6.2 Electric forklift truck with DC motor
(1) Start: Before starting, put the hand brake switch on the brake position, turn on the
urgent power-down switch, pull the shift direction switch to neutral. If not, the safe circuit
plays its part, then the forklift truck can’t start.
Turn the start switch (electric lock) clockwise to shift Ⅰto turn on the power, meter
indicator and electric control circuit, release the hand brake switch.
Push the shift direction switch forward, press down the accelerator pedal, then the
truck goes forward; if pull the direction switch backward, the reverse lamps light and the
back-up buzzers sound. If having an operational error, the meter will show relevant error
code, then reset the key switch to restart the forklift truck.
