5. Motor
5.1 DC motor
5.1.1 Main parameter
Type
Item
1-1.5t forklift truck
2-2.5t forklift truck
3t forklift truck
Drive motor
Name
Excitation
Rated power
Rated voltage
Rated current
Weight
XQ-5-3A1
Separately
5.3kw (an hour)
45V
139A
95kg
XQ-7A3
Separately
7kw (an hour)
45V
180A
60kg
XQ-10.2A
Separately
10.2kw (an hour)
75V
162.5A
115kg
Lifting motor
Name
Excitation
Rated power
Rated voltage
Rated current
Weight
XQD-8.2-1
Series
8.2kw (a quarter)
45V
240A
45kg
XQD-8.6-3D
Series
8.6kw (a quarter)
45V
248A
47kg
XQD—10-3D
Series
10kw (a quarter)
75V
160A
90kg
5.1.2 Drive motor
Installed on reduction box of drive device, the rotation of the drive motor is controlled
by low-power transistor H-axle circuit in the controller.
Rotation status of the motor is determined by the current direction that flows through
motor excitation coils.
5.1.3 Lifting motor
Lifting motor drives the main pump, it is installed on the left frame of the forklift truck.
The sketch of structure and assembly refers to Fig.5-1 and Fig.5-2.
The rotation of lifting motor is controlled by the pump controller assembled in the
counterweight.
