SETTE™ 30 MANUAL
CARE AND CLEANING
REMOVING THE BEAN HOPPER
Rotate the bean shutoff knob to the CLOSED position, then press the START button to
purge any remaining beans. Remove the power plug from the power outlet. Remove the
hopper by rotating it counterclockwise until it stops, and then lift the bean hopper off of
the grinder housing.
REMOVING THE CONE BURR/GRIND ADJUSTMENT ASSEMBLY
1. Rotate the bean shutoff knob so it is in the CLOSED position, then press the START button to run any
remaining beans through the grinder (g. C).
2. Once the grinder has been fully purged, rotate the grind adjustment assembly beyond the coarsest setting to
the install/remove indicator (blue triangle). The assembly will release downward for removal (g. E).
g. C g. D
