Barco ClickShare CSE-800 User Manual

31R5900050 /13 ClickShare CSE-800
Regional version
Contains Accessories included
R9861580NA
• R9861580
• 4x R9861500D01
• R9861500T01
• power cable NEMA 5/15
• wall/ceiling mounting brackets
• antenna extension cables
R9861580US
• R9861580
• 4x R9861500D01
• R9861500T01
• power cable SP305 IS14 1M83
• wall/ceiling mounting brackets
• antenna extension cables
Contact your local sales representative for the correct regional variant to be used in your country.
2.2 About the Base Unit
Base Unit
The Base Unit receives the wireless input from the Buttons and controls the content of the meeting
room display and the sound of the meeting room's audio system.
The Base Unit can be installed in two different ways.
Front and Top layout of the Base Unit
At the front of the Base Unit you can find a standby button and two USB ports. Status LED is mounted at the
left of the standby button.
1
2
Image 2–2
1 2x USB port 3.0
2 Standby button
USB ports
The USB ports (front or back) are used to update the soft- and firmware of both the Base Unit and the Buttons.
To pair the Buttons, connect the touchscreen and saving blackboarding/annotation screen to USB stick
2
.
Introduction to CSE-800
2. touchscreen connection, blackboarding/annotation screen saving will be available in future releases

Barco ClickShare CSE-800 Specifications

General

Brand	Barco
Model	ClickShare CSE-800
Category	Projector Accessories
Language	English
