Barco ClickShare CX-50 User Manual

39R5900095 /13 ClickShare CX-50
12 3
Image 2–53
The selection menu with Blackboard and Annotation opens on the current presented content. When
nothing is shared, only Blackboard will be available in the menu.
2. To start annotation, click on the annotation icon in the permanent bar (2)
No clients should be disconnected. The current shared screen(s) will be captured and used as
background. No previous content can be shown again.
2.16.2 Drawing tools
Pen
Click on the Pen icon (3) to start the drawing functionality. Draw with you finger on the screen.
12 3
Image 2–54
Erase
Click on the Erase icon (2) to start the erase functionality. Erasing can be done with single finger or with
multiple fingers. The eraser grows in size depending on the speed of the movement. The erased parts are
indicated with a circular overlay.
Getting started

Barco ClickShare CX-50 Specifications

General

Video outputs	1x HDMI
Video inputs	1x HDMI
Ethernet	1x RJ-45
HDMI output resolution	Up to 4K UHD (3840 x 2160)
HDMI input resolution	Up to 4K UHD (3840 x 2160)
Wireless frequency band	2.4 GHz / 5 GHz
Resolution	Up to 4K UHD (3840 x 2160)
