10 Coronis 5MP
CONNECTOR COMPARTMENT COVER OPEN
Figure 3: Rear view cover open
24 VDC Power input +5 VDC, 0.5 A power output
Display Port video input DVI video input
Ethernet connection (see
note below)
USB upstream
USB downstream 1
The Ethernet connection is used for maintenance purposes and
is not supported for user application.
